HYUNDAI IONIQ 9 ELECTRIC ESTATE

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  110.3
• Battery Charging Scenario 1 - Charge Time (Mins)
  2685
• Battery Charging Scenario 1 - Percentage Change
  10-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.3
• Battery Charging Scenario 2 - Charge Time (Mins)
  600
• Battery Charging Scenario 2 - Percentage Change
  10-100
• Battery Charging Scenario 2 - Power Supply - kW
  11
• Battery Charging Scenario 3 - Charge Time (Mins)
  109
• Battery Charging Scenario 3 - Percentage Change
  10-80
• Battery Charging Scenario 3 - Power Supply - kW
  50
• Battery Charging Scenario 4 - Charge Time (Mins)
  24
• Battery Charging Scenario 4 - Percentage Change
  10-80
• Battery Charging Scenario 4 - Power Supply - kW
  233
• Battery Type
  Lithium-ion
• Charging Port Location
  Right Side Rear
• Coupler/Connector Type
  CCS Type 2
• Maximum Charging Rate - kW
  233
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  Not Available
• WLTP - EC (kWh/100km) - Comb
  20.6
• WLTP - EC (miles/kWh) - Comb
  3
• WLTP - Pure Electric Range (km) - Comb
  600
• WLTP - Pure Electric Range (miles) - Comb
  372

Emissions - ICE

• CO
  Not Available
• CO2 (g/km)
  0
• HC
  Not Available
• HC+NOx
  Not Available
• Noise Level dB(A)
  Not Available
• NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  Not Available

Engine and Drive Train

• Camshaft
  Not Available
• Catalytic Convertor
  Not Available
• CC
  1
• Compression Ratio
  Not Available
• Cylinder Layout
  Not Available
• Cylinders
  Not Available
• Cylinders - Bore (mm)
  Not Available
• Cylinders - Stroke (mm)
  Not Available
• Engine Code
  Not Available
• Fuel Delivery
  Not Available
• Gears
  1 SPEED
• Number of Valves
  Not Available
• Transmission
  AUTO

Fuel Consumption - ICE

• EC Combined (mpg)
  Not Available
• EC Directive 1999/100/EC Applies
  Not Available
• EC Extra Urban (mpg)
  Not Available
• EC Urban (mpg)
  Not Available

General

• Alternative Fuel Qualifying
  Yes
• Badge Engine CC
• Badge Power
  427
• Based On ID
  Not Available
• Coin Description
  Not Available
• Coin Series
  Calligraphy
• Generation Mark
  1
• Insurance Group 1 - 50 Effective January 07
  49E
• NCAP Adult Occupant Protection %
  84
• NCAP Child Occupant Protection %
  87
• NCAP Overall Rating - Effective February 09
  5
• NCAP Pedestrian Protection %
  77
• NCAP Safety Assist %
  83
• Did at least one aspect of this vehicle's safety give cause for concern?
  No
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  Unlimited
• Standard manufacturers warranty - Years
  5
• Timing Belt Interval Frequency - Months
  Not Available
• Timing Belt Interval Mileage
  Not Available
• Vehicle Homologation Class
  M1

Performance

• 0 to 60 mph (secs)
  5.2
• Engine Power - BHP
  427
• Engine Power - KW
  314
• Engine Torque - LBS.FT
  516
• Engine Torque - MKG
  71.4
• Engine Torque - NM
  700
• Top Speed
  124

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  N/A

Tyres

• Alloys?
  Yes
• Space Saver?
  No
• Tyre Size Front
  285/45 R21
• Tyre Size Rear
  285/45 R21
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Type
  21" ALLOY

Vehicle Dimensions

• Height
  1790
• Length
  5060
• Wheelbase
  3130
• Width
  1980

Weight and Capacities

• Fuel Tank Capacity (Litres)
  Not Available
• Gross Vehicle Weight
  3320
• Luggage Capacity (Seats Down)
  2419
• Luggage Capacity (Seats Up)
  338
• Max. Loading Weight
  710
• Max. Roof Load
  100
• Max. Towing Weight - Braked
  2500
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  2610
• No. of Seats
  7
• Turning Circle - Kerb to Kerb
  12.48
