PEUGEOT PARTNER M DIESEL

Emissions - ICE

• HC
  Not Available
• Standard Emissions
  EURO 6
• WLTP - CO2 (g/km) - Comb - TEH
  171
• WLTP - CO2 (g/km) - Comb - TEL
  143

Engine and Drive Train

• Automatic Transmission
  Yes
• Bore
  75
• Catalytic Convertor
  Yes
• CC
  1499
• Compression Ratio
  16.4:1
• Cooling System
  WATER
• Cylinder Layout
  IN-LINE
• Cylinders
  4
• Engine Layout
  FRONT TRANSVERSE
• Engine Make
  Not Available
• Fuel Delivery
  COMMON RAIL
• Fuel Type
  DIESEL
• Gears
  8 SPEED
• Manual Transmission
  No
• Number of Valves
  16
• Stroke
  84.8
• Valve gear
  DOHC

Fuel Consumption - ICE

• EC
  No
• WLTP - FC (l/100km) - Comb - TEH
  6.5
• WLTP - FC (l/100km) - Comb - TEL
  5.4
• WLTP - MPG - Comb - TEH
  43.4
• WLTP - MPG - Comb - TEL
  51.9

General

• Alternative Fuel Qualifying
  No
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
  1.5
• Badge Power
  130
• Based On ID
  Not Available
• Chassis Engine Number
  Not Available
• Clutch
  SINGLE DRY PLATE
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  CATALYTIC CONVERTER
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  MACPHERSON STRUTS
• Generation Mark
  3
• Ghost model for valuation purposes
  No
• Hand Brake
  REAR WHEELS
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Overall Rating - LCV
  4 Star
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Rear Brakes
  DISCS
• Rear Suspension
  COIL SPRINGS
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  SMALL
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  25000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Mileage
  100000
• Standard manufacturers warranty - Years
  3
• Steering
  PAS RACK AND PINION
• This vehicle is classed as a car for VED purposes
  No
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• BHP
  131
• Engine Power KW
  96
• Engine Power RPM
  3750
• Engine Torque LBS.FT
  221
• Engine Torque MKG
  30.6
• Engine Torque NM
  300
• Engine Torque RPM
  1750
• Top Speed
  114

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  RDE 2

Tyres

• Alloys?
  No
• Automatic Clutch
  Yes
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Make
  Not Available
• Tyre Size Front
  205/60 R16
• Tyre Size Rear
  205/60 R16
• Tyre Size Spare
  TYRE REPAIR KIT
• Wheel Style
  Not Available
• Wheel Type
  16" STEEL

Vehicle Dimensions

• Front Overhang
  892
• Height
  1860
• Height (including roof rails)
  Not Available
• Length
  4403
• Load Deck Height
  588
• Load Height
  1200
• Load Length
  1817
• Load Space Width Between Wheel Arches
  1229
• Load Width
  1527
• Lower Rear Door Width
  1241
• Rear Door Height
  1196
• Rear Overhang
  726
• Side Load Door Height
  1072
• Side Load Door Width
  675
• Turning Circle - Kerb to Kerb
  10.8
• Upper Rear Door Width
  1087
• Wheelbase
  2785
• Width (excluding mirrors)
  1848
• Width (including mirrors)
  2107

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  50
• Gross Train Weight
  3400
• Gross Vehicle Weight
  2400
• Load Space Volume
  3.3
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Towing Weight - Braked
  1000
• Max. Towing Weight - Unbraked
  720
• Minimum Kerbweight
  1418
• No. of Seats
  3
• Payload
  982
• Plated 2nd Axle
  1400
• Plated Front Axle
  1200
