TOYOTA PROACE L1 ELECTRIC

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty
  70
• Battery Capacity in kWh
  75
• Battery Charging Scenario 1 - Charge Time (Mins)
  1960
• Battery Charging Scenario 1 - Percentage Change
  0-100
• Battery Charging Scenario 1 - Power Supply - kW
  2.3
• Battery Charging Scenario 2 - Charge Time (Mins)
  645
• Battery Charging Scenario 2 - Percentage Change
  0-100
• Battery Charging Scenario 2 - Power Supply - kW
  7
• Battery Charging Scenario 3 - Charge Time (Mins)
  405
• Battery Charging Scenario 3 - Percentage Change
  0-100
• Battery Charging Scenario 3 - Power Supply - kW
  11
• Battery Charging Scenario 4 - Charge Time (Mins)
  45
• Battery Charging Scenario 4 - Percentage Change
  0-80
• Battery Charging Scenario 4 - Power Supply - kW
  100
• Battery Leased
  No
• Battery Type
  Lithium-ion
• Charging Port Location
  Left Side Front
• Coupler/Connector Type
  CCS Type 2
• Maximum Charging Rate - kW
  100
• Standard manufacturers Battery warranty - Mileage
  100000
• Standard manufacturers Battery warranty - Years
  8
• Usable Battery Capacity
  75
• WLTP - EC (kWh/100km) - City
  17.9
• WLTP - EC (kWh/100km) - City - TEH
  20.2
• WLTP - EC (kWh/100km) - City - TEL
  16.6
• WLTP - EC (kWh/100km) - Comb
  23.7
• WLTP - EC (kWh/100km) - Comb - TEH
  26.4
• WLTP - EC (kWh/100km) - Comb - TEL
  22.4
• WLTP - EC (kWh/100km) - Extra High
  31.6
• WLTP - EC (kWh/100km) - Extra High - TEH
  34.7
• WLTP - EC (kWh/100km) - Extra High - TEL
  30.1
• WLTP - EC (kWh/100km) - High
  20.9
• WLTP - EC (kWh/100km) - High - TEH
  23.1
• WLTP - EC (kWh/100km) - High - TEL
  19.9
• WLTP - EC (kWh/100km) - Low
  16.9
• WLTP - EC (kWh/100km) - Low - TEH
  19
• WLTP - EC (kWh/100km) - Low - TEL
  15.6
• WLTP - EC (kWh/100km) - Medium
  18.5
• WLTP - EC (kWh/100km) - Medium - TEH
  20.8
• WLTP - EC (kWh/100km) - Medium - TEL
  17.2
• WLTP - EC (miles/kWh) - City
  3.5
• WLTP - EC (miles/kWh) - City - TEH
  3.1
• WLTP - EC (miles/kWh) - City - TEL
  3.7
• WLTP - EC (miles/kWh) - Comb
  2.6
• WLTP - EC (miles/kWh) - Comb - TEH
  2.4
• WLTP - EC (miles/kWh) - Comb - TEL
  2.8
• WLTP - EC (miles/kWh) - Extra High
  2
• WLTP - EC (miles/kWh) - Extra High - TEH
  1.8
• WLTP - EC (miles/kWh) - Extra High - TEL
  2.1
• WLTP - EC (miles/kWh) - High
  3
• WLTP - EC (miles/kWh) - High - TEH
  2.7
• WLTP - EC (miles/kWh) - High - TEL
  3.1
• WLTP - EC (miles/kWh) - Low
  3.7
• WLTP - EC (miles/kWh) - Low - TEH
  3.3
• WLTP - EC (miles/kWh) - Low - TEL
  4
• WLTP - EC (miles/kWh) - Medium
  3.4
• WLTP - EC (miles/kWh) - Medium - TEH
  3
• WLTP - EC (miles/kWh) - Medium - TEL
  3.6
• WLTP - Pure Electric Range (km) - City
  468
• WLTP - Pure Electric Range (km) - City - TEH
  410
• WLTP - Pure Electric Range (km) - City - TEL
  500
• WLTP - Pure Electric Range (km) - Comb
  351
• WLTP - Pure Electric Range (km) - Comb - TEH
  313
• WLTP - Pure Electric Range (km) - Comb - TEL
  370
• WLTP - Pure Electric Range (miles) - City
  291
• WLTP - Pure Electric Range (miles) - City - TEH
  255
• WLTP - Pure Electric Range (miles) - City - TEL
  311
• WLTP - Pure Electric Range (miles) - Comb
  218
• WLTP - Pure Electric Range (miles) - Comb - TEH
  194
• WLTP - Pure Electric Range (miles) - Comb - TEL
  230

Emissions - ICE

• CO
  Not Available
• CO2
  0
• HC
  Not Available
• HC+NOx
  Not Available
• Noise Level dB(A)
  67
• NOx
  Not Available
• Particles
  Not Available
• Standard Emissions
  Not Available

Engine and Drive Train

• Automatic Transmission
  Yes
• Bore
  Not Available
• Catalytic Convertor
  Not Available
• CC
  1
• Compression Ratio
  Not Available
• Cooling System
  Not Available
• Cylinder Layout
  Not Available
• Cylinders
  Not Available
• Engine Layout
  Not Available
• Engine Make
  Not Available
• Fuel Delivery
  Not Available
• Fuel Type
  ELECTRIC
• Gears
  1 SPEED
• Manual Transmission
  No
• Number of Valves
  Not Available
• Stroke
  Not Available
• Valve gear
  Not Available

Fuel Consumption - ICE

• EC
  Not Available
• EC Combined
  Not Available
• EC Extra Urban
  Not Available
• EC Urban
  Not Available

General

• Alternative Fuel Qualifying
  Yes
• Alternator Amps
  Not Available
• Did at least one aspect of this vehicles safety give cause for concern?
  No
• Badge Engine CC
• Badge Power
  136
• Based On ID
  Not Available
• Battery AH
  Not Available
• Battery Volts
  Not Available
• Chassis Engine Number
  Not Available
• Clutch
  Not Available
• Coin Description
  Not Available
• Coin Gross Vehicle Weight Code
  Not Available
• Coin Power Output Code
  Not Available
• Coin Series
  Not Available
• Coin Wheelbase Description Code
  Not Available
• Coin Wheelbase Name Code
  Not Available
• Exhaust System
  Not Available
• Front Brakes
  VENTILATED DISCS
• Front Suspension
  DOUBLE WISHBONE
• Generation Mark
  2
• Ghost model for valuation purposes
  No
• Insurance Group 1
  Not Available
• Insurance Group 2
  Not Available
• Manufacturers Corrosion Perforation Guarantee - Years
  6
• Manufacturers Paintwork Guarantee - Years
  3
• NCAP Adult Occupant Protection %
  Not Available
• NCAP Child Occupant Protection %
  Not Available
• NCAP Overall Rating - Effective February 09
  Not Available
• NCAP Overall Rating - LCV
  4 Star
• NCAP Pedestrian Protection %
  Not Available
• NCAP Safety Assist %
  Not Available
• Rear Brakes
  DISCS
• Rear Suspension
  LEAF SPRING
• Relative Height
  H1
• Relative Length
  L1
• Running Cost League Headings
  MEDIUM
• Service Interval Frequency - Months
  24
• Service Interval Mileage
  20000
• Special Edition
  No
• Special Order
  No
• Standard manufacturers warranty - Years
  5
• Vehicle Homologation Class
  N1
• Vin/Frame No.
  Not Available

Performance

• BHP
  136
• Engine Power KW
  100
• Engine Torque LBS.FT
  192
• Engine Torque MKG
  26.5
• Engine Torque NM
  260
• Top Speed
  81

Test Cycles

• Emissions Test Cycle
  WLTP
• RDE Certification Level
  Not Available

Tyres

• Alloys?
  Yes
• Automatic Clutch
  Not Available
• Plated 3rd Axle
  Not Available
• Plated 4th Axle
  Not Available
• Space Saver?
  No
• Tyre Size Front
  215/60 R17
• Tyre Size Rear
  215/60 R17
• Tyre Size Spare
  FULL SIZE
• Wheel Style
  5 DOUBLE SPOKE
• Wheel Type
  17" ALLOY

Vehicle Dimensions

• Front Overhang
  902
• Height
  1910
• Length
  4981
• Load Height
  1397
• Load Length
  2512
• Load Width
  1636
• Rear Overhang
  803
• Turning Circle - Kerb to Kerb
  12.4
• Turning Circle - Wall to Wall
  12.9
• Wheelbase
  3275
• Width (excluding mirrors)
  1924
• Width (including mirrors)
  2204

Weight and Capacities

• Boot Capacity Saloons
  Not Available
• Fuel Tank Capacity (Litres)
  Not Available
• Gross Train Weight
  4021
• Gross Vehicle Weight
  3021
• Load Space Volume
  5.8
• Luggage Capacity (Seats Down)
  Not Available
• Luggage Capacity (Seats Up)
  Not Available
• Luggage Capacity - 2nd Row Seats Removed
  Not Available
• Luggage Capacity - 2nd Row Seats Up
  Not Available
• Luggage Capacity - 3rd Row Seats Down
  Not Available
• Luggage Capacity - 3rd Row Seats Removed
  Not Available
• Luggage Capacity - 3rd Row Seats Up
  Not Available
• Max. Towing Weight - Braked
  1000
• Max. Towing Weight - Unbraked
  750
• Minimum Kerbweight
  1810
• No. of Seats
  3
• Payload
  1211
• Plated 2nd Axle
  1618
• Plated Front Axle
  1630
